MICAP-OES 1000

The Most Innovative Microwave Inductively Coupled Plasma Emission Spectrometer On The Market

Unique Design

Unique Performance

No Argon Dependency

Runs on Nitrogen

Nitrogen costs less and can be generated locally. Also eliminates need for combustible gases in remote locations.

Consumes Less

Power

MICAP operates on 208V to 240V electrical power from regular outlets or remote generators.

Air Cooled

No Chiller Required

With no water chiller required, maintenance and overheated rooms are a thing of the past.

Cumulative Costs of Ownership Image

Lowest Total Cost of Ownership

MICAP-OES 1000 pays for itself in less than 3 years and saves you over $200k during its product life.

Learn How To Save More

Annual CO2e Emissions Savings Compared to Argon Carbon Footprint

Carbon Footprint Symbol Icon

Based on standard Argon cylinders. Source:
EPA.GOV (https://www.epa.gov/energy/greenhouse-gas-equivalencies-calculator.)

MICAP + RIS
kWh saved
1,772,640
metric tons of CO2e saved
1,256

Equivalent to:

Home’s annual electricity use
244
Gasoline-powered passenger vehicles
280
Total gallons of gasoline consumed
141
Total smartphones charged
152,812,225
Spectrometer Image

Optical Emission Spectrometer

Echelle spectrometer simultaneously measures the entire wavelength range with every solution injection.

Wavelength range: 194 nm – 625 nm + 766 nm

Resolution 5pm – 30 pm, 7 pm at 200 nm

FAQ

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

CERAWAVE Logo
Revolutionary
Cerawave Ring
Cerawave Ring Image
Cerawave Ring Image

Produces highly efficient plasma energy coupling

The innovative ceramic waveguide design transfers microwave energy into the plasma.  Minimal energy is wasted as heat during the transmission process. The ring is precisely engineered to match the impedance of the plasma, ensuring optimal energy transfer.

Eliminates need for water cooling

The elimination of water-cooled coils presents a paradigm shift in plasma science. The MICAP removes the dependency on external water chillers that flood a laboratory with excess heat and noise.

Provides superior sample matrix tolerance

Traditional microwave plasma methods often struggle with maintaining stable performance in the presence of heavy sample matrix levels. The patented Cerawave technology ensures maximum energy coupling for optimum stability in difficult samples.

MICAP-OES 1000 Applications

Product Specification

MICAP-OES 1000 Plasma Source

MICAP Dimensions Image

Standard torch dimensions (20 mm) with 1.5 mm injector (2.5 mm injector option) designed around the fixed position torch holder assembly.

Variable speed four-channel peristaltic pump and concentric 1 mL/min nebulizer are standard sample introduction assembly (SIA) components.

Vertical torch position with axial viewing and automated, uniform plasma tail removal.

Echelle Spectrometer simultaneously measures the entire wavelength range with every solution injection.

Power requirements:
  • Mains power: 208 V to 240 V/10 A
  • No water cooling required
Exhaust:
  • 4 inch (100 mm) exhaust with flow rate between 100 – 200 cfm (1.5 – 2.9 m/s)
Gas flows:
  • Mass flow controlled coolant, auxillary and nebulizer gas for reliable and stable sample measurement
  • Typical plasma gas flow is 14L/min
  • Nitrogen gas can be sourced from liquid dewar, compressed gas cylinder or nitrogen generator
Size:
  • [W] 20.7 in (525 mm) x [H] 22 in (560 mm) x [D] 14 in (350 mm)
Weight:
  • MICAP Plasma Source Unit 42 lbs (19 kg)
  • Total weight of MICAP with Spectrometer 67 lbs (30 kg)

Camera

Detector
  • sCMOS
Array diagonal:
  • 31 mm
Resolution:
  • 2048 x 2048
Cooling:
  • Peltier cooled to -10 °C
Other parameters:
  • Pixel size: 11 µm x 11 µm
  • Frame rate: 24 fps

Optical Emission Spectrometer

Wavelength range:
  • Simultaneous measurement 194 nm – 625 nm + 766 nm
Slit Width:
  • 30 um slit
Resolution:
  • 5pm – 30 pm, 7 pm at 200 nm
Operating environment:
  • Temperature: 20 - 25 °C (68 - 77 °F)
  • Relative Humidity: 20-60 %
